X-Ray Tube (光管) |
| Structure (結構) |
Industrial package Air Cooling X-Ray Tube
(工業級氣冷包覆式光管) |
| Emission Type (照射方式) |
Continuance (連續式) |
| Power Rate (功率) |
15 Watts |
| Maxi. Voltage Output (最大輸出電壓) |
80 KV |
| Maxi. Current Output (最大輸出電流) |
250 Microamps |
| Focal Spot Size (光束直徑) |
40 Microns |
X-Ray Image Detector (影像接收器) |
| Structure (結構) |
Image Intensifier,Lens and CCD
(影像增強器、鏡頭及CCD組合) |
| F.O.V (視野範圍) |
25 mm |
| Resolution (解析度) |
25 lp/mm |
| Zoom In / Out (倍率) |
7X~35X |
Working Table (工作平台) |
| Table Size (平台尺寸) |
290mm x 290mm |
| X & Y Axes Stroke (XY軸行程) |
200mm x 200mm |
| Movement Type (運行方式) |
Manual (手動) |
3D Inspection (立體檢測) |
| θ axis range (θ軸傾斜範圍) |
+/- 30° |
Whole System (全系統) |
| Volumn (體積) |
650mm (W) x 739mm (D) x 882mm (H) |
| Weight (重量) |
120 Kgs |
| Leakage (洩漏量) |
0.5μSv. / hr |
| Power (動力源) |
110v / 220v 50-60 Hz |
| Safety Standard (安全標準) |
U.S.A. Radiation Safety Califonia Data Sheet 5900-0063. Rev.1 |
PC (電腦) |
| Motherboard (主機板) |
Pentium 4，524，3.06G，1MB，L2/533MHz |
| CPU (中央處理器) |
512MB，DDR II ，667 SD RAM (512*1) |
| Memory (記憶體) |
80 GNB，7200rpm / Serial ATA |
| Display (顯示器) |
19" TFT LCD Monitor |
| Options (配件) |
Printer 影像列印機 |
| Measuring Software (量測軟體) |
Distance (points, lines) , Circle , Area & Angle |
